Cardboard Packaging machines

Solution FLEXPACKER US Box case erector, top loading.

Automatic box forming machine with stainless steel frame for forming, filling and closing American boxes.

The carton is picked from the store magazine and, during its transfer to the opening and formation area, adhesive tape or hotmelt bonding is applied on the lower sections, allowing the closing of the bottom of the box.

The resulting US box is loaded into the filling station. A matrix of the same size of the US box keeps the carton edges aligned, allowing a guided/smoother casing and consequently a precise positioning of the products.

Products are inserted in the US box by means of a robotized pick-and-place delta system with suction cups or other gripping system, controlled by a shaft motor.

After filling, a transfer module pushes the US boxes towards an exit module conveyor. The boxes are finally sealed with adhesive tape or hotmelt glue.The flow then moves to a manual or automatic palletizing station.

Solution FLEXPACKER WA wrap around case former, lateral or top loading.

Automatic WA (wrap-around) box forming machine with automatic grouping system through a dynamic motorized preparation table. Regardless of the type of product handled, the cardboard packer machine FLEX PACKER WA can handle the grouping and filling of products for the forming of the wrap-around cardboard box.

A cycler distributes pots, bottles or other products on a preparatory “flex table” constantly motorized, so that the brushless motor can carry out a continuous working cycle.

This alternative solution guarantees a continuous input flow, allowing for lateral filling or top loading.This preparatory table assembly can be fitted for automatic format changing by adding brushless positioning motors (optional).

The preparatory table works in a flexible manner respecting the shapes of the single products.

Pick-and-place solution primarily designed for yogurt cups or blister packs lines in the dairy industry as well as for cream, dairy desserts, jams, compote etc.

CIAM PACK FLEXPACKER PICK & PLACE, automatic packaging machine with robotized pick-and-pace device suitable for packaging a variety of products in cardboard trays with cavity cups; thanks to its stainless steel frame, it is ideal for industrial environments where aggressive and frequent cleaning with corrosive products is necessary, particularly in the dairy sector.

It is a flexible solution designed for high accessibility and flexibility, respecting ergonomic standards, in accordance with safety requirements.

The machine is made up of a series of integrated modules capable of operating at high production speeds.

The machine configuration is dynamic and fluid, allowing the implementation of different devices according to the project’s requirements – as a special motorized “fly bars” conveyor. The pick-and-place of the products is carried out by means of a tailored-made picking head which can guarantee the safe handling of the cups and the filling of two trays simultaneously.

The robotic station seamlessly integrates into the packaging island already present on the line, consisting of a tray former machine and filling machine, with which it works in perfect synchrony and continuity.

Software integration and management are supplied by CIAM PACK.

The system combines perfectly with box forming and closing solutions and with machines for the insertion of single pots in trays with cavities.

Easy tool-free or automatic change of the robotic gripping head.
